Datasheet

TRACKING SERIES AND PARALLEL FUNCTION

For series and parallel applications of CH1 and CH2, the tracking

function of the GPP-Series utilizes the internal circuit to

automatically switch the output to serial or parallel output without

additional external wiring, providing users with convenience not

only in operating procedures but also a more stable output.

The output monitoring function allows users to set the monitoring

conditions according to the requirements, including the voltage,

current, and power greater than or less than the setting and the

logical relationship of AND, OR. It also allows users to sound

OUTPUT MONITORING FUNCTION

SEQUENCE OUTPUT FUNCTION

The tracking function design of other brands requires additional

external wiring connections for the output in series or parallel.

However, excessively long, thin or inconsistent external wiring

may cause inaccurate voltage or current output.

Output Monitoring

Output Waveform of the GPP-X323 Series

Monitoring Function Setting

alarms or stop the output during the measurement process, stop

the measurement, and protect the customer's DUT. Each Channel

could be monitored simultaneously as well.

Output in Parallel Connections

Output in Series Connections

The GPP-Series provides a sequential output function on Channel 1

and Channel 2. This function not only allows users to edit the

power output waveform, but also allows users to set the sequential

constant voltage (CV) or constant current (CC) load waveform, i.e.

a serial power output or a simulation test of a dynamic load. The

maximum settable points for sequence function are 2048, and

interval range of each point can be set from 1 to 300 seconds. In

order to simplify the setting of waveform editing, the GPP-Series

has 8 built-in Templet waveforms in sequence output function for

The editing data of the sequence output can be stored in the

internal 10 sets of the memory, or to be saved by USB flash drive

(Save/Recall) and saved as *.SEQ or *.CSV file; The stored *.CSV

can be exported into Excel for editing and analysis. The final

edited file can be imported to (Save/Recall) of the power supply

using a USB flash drive.

users to directly apply for output, including Sine, Pulse, Ramp,

Stair Up, Stair Dn, Stair UpDn, Exp Rise, and Exp Fall waveforms.
