Instruction Manual

GETTING STARTED

Required tools

•

GDS-3000 x 1 or GDS-2000A x 1

• Demo board x 1

• USB type A- type B cable x 1. Used for demo board’s power

• Deep memory: 25k points record length(For GDS-3000)

• Deep memory: 2M points record length(For GDS-2000A)

• Standard oscilloscope probe x 4

• DS2-08LA or DS2-16LA(For GDS-2000A only)

Demonstration type

GDS-3000

• VPO (page16)

• Split window 1 (page 18)

• Split window 2 (page 19)

• Auto Range Function (page 21)

• Autoset mode (page 22)

• XY mode (page 25)

• Gating Measurement (page 27)

• Pulse Runt (page 28)

• Rise Fall (page 30)

• Pulse Width (page 31)

• UART (page 33)

• I

C (page 35)

• SPI (page 36)

• Delay(page 38)

• FM (page 40)

• Video (page 42)

GDS-2000A

• Autoset mode (page 55)

• XY mode (page 57)

• Gating Measurement (page 59)

• Pulse Runt (page 60)

• Rise Fall (page 62)

• Search (page 63)

• Segments (page 65)

• Parallel (page 66)

• Pulse Width (page 68)

• Delay (page 70)

• LM(Long Memory)(page 72)

• Logic (page 74)

• UART (page 75)

• I

C (page 77)

• SPI (page 78)

• CAN(page 80)
