GDB-03 Demo Module User Manual

GDS-2000A Series Overview

Series lineup

The GDS-2000A series consists of 8 models, divided into 2-channel

and 4-channel versions.

Model name Frequency

bandwidth

Input channels Real-time

Sampling Rate

GDS-2072A 70MHz 2 2GSa/s

GDS-2102A 100MHz 2 2GSa/s

GDS-2202A 200MHz 2 2GSa/s

GDS-2302A 300MHz 2 2GSa/s

GDS-2074A 70MHz 4 2GSa/s

GDS-2104A 100MHz 4 2GSa/s

GDS-2204A 200MHz 4 2GSa/s

GDS-2304A 300MHz 4 2GSa/s

2-Channel model

4-Channel model
