GDB-03 Demo Module User Manual
2
GETTING STARTED
Using the demo board specially designed for
GDS-2000A and GDS-3000, you can verify and
observe various advanced functionalities for
demonstration or your own education. For
viewing demo waveforms on the GDS-3000,
please refer to page 9 through page 47. For
viewing demo waveforms on the GDS-2000A,
please refer to page 48 through page 90.
GDS-3000 Series Overview
Series lineup
The GDS-3000 series consists of 6 models, divided into 2-channel
and 4-channel versions.
Model name Frequency
bandwidth
Input channels Real-time
Sampling Rate
GDS-3152 150MHz 2 2.5GSa/s
GDS-3252 250MHz 2 2.5GSa/s
GDS-3352 350MHz 2 5GSa/s
GDS-3502 500MHz 2 4GSa/s
GDS-3154 150MHz 4 5GSa/s
GDS-3254 250MHz 4 5GSa/s
GDS-3354 350MHz 4 5GSa/s
GDS-3504 500MHz 4 4GSa/s
