Instruction Manual

GDB-03 Demo Module User Manual
21
Display Auto-Range Function (Analog Mode 4)
Background
Demonstrate that the oscilloscope can
automatically be adjusted to the best range setting
according to changes in the input signal.
Step
1. Press the Test key on the front
panel of the GDS-3000.
2. Press the Demo button.
3. Press the Down button to select
Analog Mode 4. A screen
confirming Analog Mode 4 is
selected as shown below appears.
4. Press the Run button and Auto-
Range key to display the
waveform.
