System Specifications (Continued)
General Specifications
Frequency band 9200 - 9300 MHz
Four xed, user-selectable frequency pairs Pair Mobile Station Fixed Station
0 9200 MHz 9230 MHz
1 9300 MHz 9270 MHz
2 9230 MHz 9200 MHz
3 9270 MHz 9300 MHz
Radiated power 100 mW max 100 mW max 100 mW max
Polarisation Vertical Vertical Vertical
Range
With omni directional antenna type AT-120 10m – 2,500m
With semi omni directional antenna type AT-010 10m – 5,000m
With horn antenna type ATH-010A 15m – 1,000m
Supply voltage 220-240 VAC,
50-60 Hz
220-240 VAC,
50-60 Hz
220-240 VAC,
50-60 Hz
Beacon
Guidance Marine reserves the right to alter or amend this published specification without notice.
