1.4. Main Parameter
The detailed technical parameters of this series of products are as follows:
Table 1 Description of main technical parameters of the product
Parameter/Model
RD5201
RD5206
RD5212
RD5224
RD5230
Operating
Frequency
13.56 MHz
Support
Standard
ISO/IEC 15693 and ISO/IEC 18000-3M1
RF Power
1~8W(configurable, the system default setting is 4W)
Antenna
Interface
SMA×1
SMA×6
SMA×12
SMA×24
SMA×30
Communication
Interface
RS232, RS485, Ethernet, USB
Working Mode
host mode and auto read mode（configurable）
Supply Voltage
12V DC
Maximum
Power
Consumption
≤22W
Shell Material
aluminum alloy
metal plate
Dimensions
200×168×33mm
308.5×207×
38mm
438.6×207×
38mm
Maximum
Operating
Temperature
50℃
2. Hardware Interface Description
2.1. Overview
Due to the different number of antenna interfaces in this series, the sizes of some
models are also different, but the appearance and the interfaces of each model is
basically the same, so model RD5212 is taken as an example in the following
description.
