User's Manual

9
5. Gently push tone arm clip (5)
to the right to release the tone arm.
6. Raise the cue lever (6) to lift the tone arm off the tone arm support.
7. Move the tone arm gently to the edge of the record (or the starting point of a track).
The turntable will begin to turn.
8. Gently lower the tone arm by slowly releasing the cue lever.
9. When playback is finished, the tone arm will automatically return to its holder, and indicator light
will light up, Then the turntable will stop. To stop playback manually, slightly lift the tone arm using
the cue lever and return it to the tone arm holder.
Note: It will take approximately 20 seconds for tone arm to return to its holder when playing a 78
rpm record.
Important:
- Closing the top cover will help prevent dust from settling on the turntable.
- Always relock the tone arm clip before transporting the unit.
- Do not place anything on top of the turntable cover, especially while playing a record.
Listening to a CD
1. Press the “CD” selector button (1).
“--- BUSY CD” will blink for a few seconds.
Note: When no disc is set, “NO DISC” will appear on
the display.
2. Press the OPEN/CLOSE button
(Note: This button will not work in AM/FM mode)
3. Place a disc on the tray with the printed label face up.
4. Press the OPEN/CLOSE button to close the tray.
5. Press the PLAY/PAUSE button (
) to begin playback.
6. To temporarily pause playback, press the PLAY/PAUSE button (
). Press again to resume.
7. To skip tracks forward or backward, press the corresponding skip button (
or ).
Pressing
one will restart the current track. Pressing twice in succession will return to
the beginning of the previous track.
8. To fast forward / rewind within a track, press and hold down the corresponding skip button until
the desired position is reached.
9. To stop playback, press the STOP
button
Important:
- Never place more than one disc on the tray.
- The disc must be placed in the center of the disc tray. An incorrectly loaded disc can
permanently damage the tray door mechanism.
- Do not push the CD tray – always use the OPEN/CLOSE button.
- It takes a moment for the unit to load a disc, during which all buttons will be temporarily
deactivated.
