1.2. GST Smart-Cell Repeater Advantages
It provides selectable RF power levels for any wireless technology / band.
It has individual monitoring multiple technology.
FPGA digital filtering provides optimized RF performance.
It allows modification of technology via customer interface.
It is easily installed.
Frequency is easy to add / delete / change.
It has scalable single and multi-service design.
Customer data service is improved by adding 4G (LTE)
It meets all Verizon’s technology requirements.
It guarantees 5 year warranty for all individual components.
Its modular design is a customer friendly and efficient.
1.3. Repeater Operation
Simple replacing of the amplifier unit allows changing the service. Smart-Cell repeater
provides service at 700MHz, 800MHz, 850MHz, 1900MHz, 2100MHz, 2500MHz and
2600MHz. One PSU supplies electricity to maximum 4 amplifier units
Frequency Service Device Name Remarks
700 LTE SMT-L33
800 iDEN SMT-I33
850 Cellular SMT-C33
1900 PCS SMT-P33
2100 AWS SMT-A33
2500 TD-LTE SMT-T33
2600 BRS SMT-B33
