Repeater User Manual
SmartCell Repeater
36
Check the input level
-Increase output power or check input change of
BTS side
Check gain of the unit
-If the Gain is different from normal level, please
contact A/S team
Cable connector loose
-It is possible for connectors to get too tight and
damage the equipment or throughput
-Please contact installer or service provider upon
verification
In case of
dropped call
or bad
signal after
set up
Check input signal
strength in the service
area
-
Increase output power level of repeater by
adjusting attenuation level
If input signal strength
is not a problem,
please check delay of
calling time
-Increase output level of Uplink signal, then set to
optimal level.
Check RSSI signal
strength
-
Contact network management team or service
provider
In case
output
Signal
wavelength
is not shown
flat or looks
like
oscillation
Check connection
fastened between
antenna and cable
(Signal wavelength
should be flat and
stable if technicians
shake CABLE. If not, it is
connection problem)
-
If connection is not proper, reconnect cable and
connector and then check the output power again
Input level change or
module overheating
-Check input level from BTS side.
-Check performance of each module (Diagnosed
by A/S team)
Please check VSWR of
the cable is normal
-Change to normal Cable
