Repeater User Manual
SmartCell Repeater
35
When in
alarming
DL VSWR alarm
Please Check following status;
-Make sure Server Antenna Port is disconnected.
-
Please reset Adapter upon completing Alarm
troubleshooting
DL over-output alarm
-Make sure output power is operating normally
-
Please Reset Adapter upon completing Alarm
troubleshooting
UL over-output alarm
-Please make
sure output level is operating
normally
-
Please reset Adapter upon completing Alarm
troubleshooting
Temperature alarm
Check following status;
-Setting level of maximum temperature limit
-Temperature offset is normal or not
-Circumstances of temperature
-
Please Reset Adapter upon completing Alarm
troubleshooting
RF off
-Verify that the HPA’s are On
-
Please Reset Adapter upon completing Alarm
troubleshooting
When
output
power is no
longer
problem
Technician should verify
category of alarm at
the front side of
repeater
-When Red light on the Shutdown LED, technician
should troubleshoot the alarm via Notebook
computer
-Technician should
connect antenna with
output port of repeater
-Please make sure all
connectors are fastened
-Reconnect the connector
-Change it if the connector is defective
