User Manual
Table Of Contents
- 1. INTRODUCTION
- 2. SYSTEM CONFIGURATION
- 2.1. Smart-Cell Repeater Service Network Configuration
- 2.2. System Design and Operation
- 2.2.1. System Design
- 2.2.2. Downlink/ Uplink Path
- 2.2.3. 700MHz Frequency Selection (LTE)
- 2.2.4. 800MHz Frequency Selection (iDEN)
- 2.2.5. 850MHz Frequency Selection (Cellular)
- 2.2.6. 1900MHz Frequency Selection (PCS)
- 2.2.7. 2100MHz Frequency Selection (AWS)
- 2.2.8. 2600MHz Frequency Selection (BRS)
- 2.2.9. 2500MHz Frequency Selection (TD-LTE)
- 3. SYSTEM SPECIFICATIONS
- 4. SETUP
Repeater User Manual
SmartCell Repeater
34
Item Check Point Troubleshooting
Check
before
system
operation
System input power
range
-Downlink: -100dBm ~ -27dBm
-Uplink: -100dBm ~ -27dBm
System gain
(DL/UL)
- 60dB ~ 90dB
Output power
at server port
- Downlink: 33dBm ± 2dB
- Uplink: 33dBm ± 2dB
Check points before
open for service
-
Please check quantity of all accessories with
specification before you set up
-
Fit cable length in accordance with field
condition
Check after
system
operation
Check points after open
for service
Check following status;
-
Verify that the antennas are securely mounted
and pointed in the correct directions
-
Connection status between antennas and RF
cable
-Verify that the Repeater is securely mounted
-Proper AC power status
-Grounding status of electrical circuit
-Coaxial cable (RF) construction status
-Connectors and combiners connection status
-Cable connec
tion status against leakage of
water
When
repeater
does not
work
properly
Check electricity cord
connection status
-Re-plug in Adapter cord
