User Manual
Table Of Contents
- 1. INTRODUCTION
- 2. SYSTEM CONFIGURATION
- 2.1. Smart-Cell Repeater Service Network Configuration
- 2.2. System Design and Operation
- 2.2.1. System Design
- 2.2.2. Downlink/ Uplink Path
- 2.2.3. 700MHz Frequency Selection (LTE)
- 2.2.4. 800MHz Frequency Selection (iDEN)
- 2.2.5. 850MHz Frequency Selection (Cellular)
- 2.2.6. 1900MHz Frequency Selection (PCS)
- 2.2.7. 2100MHz Frequency Selection (AWS)
- 2.2.8. 2600MHz Frequency Selection (BRS)
- 2.2.9. 2500MHz Frequency Selection (TD-LTE)
- 3. SYSTEM SPECIFICATIONS
- 4. SETUP
Repeater User Manual
SmartCell Repeater
29
4.3. Web UI Ranges Table
GUI Feature Range Description
Downlink and Uplink Output
Power Display
Below 0dBm to
35dBm
The output Power of the Repeater
Downlink Low RF Power 2dB to 10dB Threshold for Low RF Power
Downlink and Uplink
Attenuation Control
0dB to 30dB Reduces Gain Internally
Downlink and Uplink ALC
Limit
0dBm to 33dBm Limits Output Power
Downlink RSSI Display -100dBm to -27dBm
Downlink Receive Level at Donor
Antenna Port
Downlink Low RSSI -93dBm to -57dBm Threshold for Low RSSI
Downlink and Uplink AMP
Control
On/Off High Powered Amplifier
Gain Balance Control On/Off Equalizes Uplink and Downlink Gain
Gain Balance Value 0dB to 15dB Subtract Uplink Gain by G/B Value
Shutdown Control On/Off Shutdown if Major Alarm is Reported
Auto Gain Setting On/Off
Automatic Gain Setting for the
Repeater
Auto Oscillation Check On/Off Preventing Oscillation
Temperature Display 32 to 260.6 Degrees Internal Repeater Temperature
AMP Temperature Upper
Limit
0 to 299 Degrees Threshold for Temperature Alarm
Band Blocks Used/Bandwidth Each AMP
The Channel the Repeater will be
using
Delay Alarm Report 0 or 5 Minutes
Time Delay of Reporting after Alarm
is Detected
