User Manual
Table Of Contents
- 1. INTRODUCTION
- 2. SYSTEM CONFIGURATION
- 2.1. Smart-Cell Repeater Service Network Configuration
- 2.2. System Design and Operation
- 2.2.1. System Design
- 2.2.2. Downlink/ Uplink Path
- 2.2.3. 700MHz Frequency Selection (LTE)
- 2.2.4. 800MHz Frequency Selection (iDEN)
- 2.2.5. 850MHz Frequency Selection (Cellular)
- 2.2.6. 1900MHz Frequency Selection (PCS)
- 2.2.7. 2100MHz Frequency Selection (AWS)
- 2.2.8. 2600MHz Frequency Selection (BRS)
- 2.2.9. 2500MHz Frequency Selection (TD-LTE)
- 3. SYSTEM SPECIFICATIONS
- 4. SETUP
Repeater User Manual
SmartCell Repeater
25
4. SETUP
4.1. Equipment Needed for Repeater Setup
Parameter Item Quantity Remark
Major Component Smart-Cell Repeater 1 EA Provided by GST
Additional
Components
WALL Mounting Bracket
CD which contains User Manual
V.1.0 and Installation Guide V.1.0
Ethernet Cable 6.6ft (2m)
Ground Cable 6.6ft (2m)
Ground SEMs Screw M4 x 8mm
Bracket SEMs Screw M6 x
10mm
Lag Screw 12.7mm x 50.8mm
FEU-AMP unit cable
FEU-Wall Bracket cable
1 EA
1 EA
1 EA
1 EA
4 EA
4 EA
4 EA
8 EA
2 EA
Provided by GST
Antenna
Donor ANT
Service ANT
1 EA
1 EA
Not Included
RF Cable Antenna connection Cable TBD Not Included
Testing and
Measuring
Equipment
Spectrum Analyzer 1 EA Not Included
4.1.1. Check points before turning on the Repeater
1) System Power Check
① AC electrical power to the repeater should be 110V, input electricity only after
power verification.
2) Input RF Signal Range
① Optimal input RSSI into the repeater is -57dBm ~ -27dBm for
700MHz/850MHz/1900MHz/2100MHz/2500MHz/2600MHz. User should verify
