User Manual
Table Of Contents
- 1. INTRODUCTION
- 2. SYSTEM CONFIGURATION
- 2.1. Smart-Cell Repeater Service Network Configuration
- 2.2. System Design and Operation
- 2.2.1. System Design
- 2.2.2. Downlink/ Uplink Path
- 2.2.3. 700MHz Frequency Selection (LTE)
- 2.2.4. 800MHz Frequency Selection (iDEN)
- 2.2.5. 850MHz Frequency Selection (Cellular)
- 2.2.6. 1900MHz Frequency Selection (PCS)
- 2.2.7. 2100MHz Frequency Selection (AWS)
- 2.2.8. 2600MHz Frequency Selection (BRS)
- 2.2.9. 2500MHz Frequency Selection (TD-LTE)
- 3. SYSTEM SPECIFICATIONS
- 4. SETUP
Repeater User Manual
SmartCell Repeater
23
Auto Limit
Control
• Used for DAS configuration and when oscillation/isolation is a concern.
• Automatic Gain decrement when output power of repeater is higher than default
level.
• Automatic Gain recovery when output power of repeater is reduced.
• Shutdown when output power is higher than default level in the minimum gain.
• Automatic Recovery Algorithm conversion after shutdown status.
Band Select
• 700MHz : Lower A(5MHz)/Lower B(5MHz)/ Lower C(5MHz)/Upper C(10MHz)
• 800MHz: 5MHz/10MHz
• 850MHz : A1(11MHz)/B1(10MHz)/A2(1.5MHz)/B2(2.5MHz)
• 1900MHz : 1.25MHz ~ 20MHz/1.25MHz step
• 2100MHz: 5MHz/10MHz
• 2500MHz: 20MHz
• 2600MHz: 5MHz/10MHz/15MHz/20MHz
Power
Monitoring
• Monitoring repeater’s output level.
Oscillation
Check
• Isolation Check in initial set up or Reset.
• When Oscillation occurred, repeater attempts to stabilize Isolation through Gain
control function.
• Shutdown repeater when oscillation still occurs in the minimum Gain.
• Automatic Recovery Algorithm conversion after shutdown status.
Automatic
Recovery
• When repeater is shutdown, it periodically recovers output power of repeater
then monitors alarming.
Security
• Support HTTPS for Web Browser security.
• User authentication through User ID and Password.
AOC
Auto
Oscillation
Check Function
• AOC Use for prevented oscillation
