User Manual
Table Of Contents
- 1. INTRODUCTION
- 2. SYSTEM CONFIGURATION
- 2.1. Smart-Cell Repeater Service Network Configuration
- 2.2. System Design and Operation
- 2.2.1. System Design
- 2.2.2. Downlink/ Uplink Path
- 2.2.3. 700MHz Frequency Selection (LTE)
- 2.2.4. 800MHz Frequency Selection (iDEN)
- 2.2.5. 850MHz Frequency Selection (Cellular)
- 2.2.6. 1900MHz Frequency Selection (PCS)
- 2.2.7. 2100MHz Frequency Selection (AWS)
- 2.2.8. 2600MHz Frequency Selection (BRS)
- 2.2.9. 2500MHz Frequency Selection (TD-LTE)
- 3. SYSTEM SPECIFICATIONS
- 4. SETUP
Repeater User Manual
SmartCell Repeater
22
2100MHz ±1MHz ＞ 40dBc
2500MHz ±1MHz ＞ 50dBc
2600MHz ±1MHz ＞ 50dBc
Characteristic Impedance 50Ω
3.3. Electrical and Environmental Specifications
Item Specification Remark
RF Connector N-Type Female Donor & Server ANT Port
AC Supply AC 110V 60Hz 3.0A
Out Dimension
3.1” x 15.5” x 7.7” AMP unit
19” x 19” x 7.9” System (Rack mount)
Weight
700MHz 13.0lbs 5.89 ㎏
800MHz 11.5lbs 5.21 ㎏
850MHz 11.5lbs 5.21 ㎏
1900MHz 11.5lbs 5.21 ㎏
2100MHz 10.0lbs 4.53 ㎏
2500MHz 12.0lbs 5.44 ㎏
2600MHz 11.5lbs 5.21 ㎏
FEU 23
19” rack + NMS + PSU
(except AMP units and FEU)
Operation Temperature -10℃ ~ +50℃ Convection cooling
Humidity 5% ~ 95% Non-condensing
Vibration Resistance
1G, 10~150Hz
0.1 Octaves/min
MTBF 50,000 hours
3.4. Functions
Parameter Specification
Gain Control
• Adjustable DL and UL Gain range 60dB ~ 90dB.
• Display default Gain and current Gain function
ALC • To limit output powers as far as default range.
