Repeater User Manual
SmartCell Repeater
21
3.2. System Specifications
Parameter Specification Remark
Gain
Range 60dB ~ 90dB
Adjust Step ±0.5dB
Adjust Accuracy ±1dB
Flatness
700MHz
< 3.0dBp-p
800MHz
2500MHz
2600MHz
850MHz
< 5.0dBp-p
1900MHz
2100MHz
Propagation Delay ≤ 6us
VSWR 1.7 : 1
Noise Figure Max Gain < 7dB
ACP
750MHz > 45dBc @±5MHz/10MHz
800MHz
> 45dBc ±750KHz
> 50dBc@±1.98KHz
CDMA
> 45dBc @±5MHz/10MHz LTE
850MHz
> 45 dBc ±885KHz
> 52dBc@±1.98KHz
<-13dBm@Fc±2.25MHz (RBW: 1MHz)
1900MHz
> 45 dBc ±750KHz
> 52dBc@±1.98KHz
<-13dBm@Fc±2.25MHz (RBW: 1MHz)
2100MHz > 45dBc @±5MHz/10MHz
2500MHz > 45dBc @±5MHz/10MHz
2600MHz > 45dBc @±20MHz
Roll off
700MHz ±1MHz ＞ 45dBc
800MHz ±1MHz ＞ 45dBc
850MHz
±1MHz ＞ 45dBc
±250kHz ＞ 30dBc
1900MHz ±1MHz ＞ 50dBc
