Repeater User Manual
SmartCell Repeater
20
3. SYSTEM SPECIFICATIONS
3.1. RF Performance
Item Specification Remark
Frequency
700MHz
DL : 728.5MHz ~ 745.5MHz
746MHz ~ 756MHz
UL : 698.5MHz ~ 715.5MHz
777MHz ~ 787MHz
5MHz / 10MHz
800MHz
DL : 862MHz ~ 863.8MHz
864MHz ~ 868.6MHz
UL : 817MHz ~ 818.8MHz
819MHz ~ 823.6MHz
1.8MHz + 4.8MHz
850MHz
DL : 869MHz ~ 894MHz
UL : 824MHz ~ 849MHz
25MHz
1900MHz
DL : 1930MHz ~ 1990MHz
UL : 1850MHz ~ 1910MHz
60MHz
2100MHz
DL : 2145MHz ~ 2155MHz
UL : 1745MHz ~ 1755MHz
10MHz
2500MHz 2496MHz ~ 2690MHz 194MHz
2600MHz
DL : 2620MHz ~ 2690MHz
UL : 2500MHz ~ 2570MHz
70MHz
Maximum Input Power -27dBm
Output Power (ANT Port) +33dBm / 2W Tot al
