Repeater User Manual
SmartCell Repeater
19
L27 2629.80 2638.80 2647.80 18.00 E1,E2,E3,F1,F2
L33 2633.10 2642.10 2651.10 18.00 E2,E3,F1,F2,F3
L38 2636.60 2645.60 2654.60 18.00 E3,F1,F2,F3
L07 2639.60 2648.60 2657.60 18.00 E3,F1,F2,F3,H1
L14 2643.10 2652.10 2661.10 18.00 F1,F2,F3,H1
L21 2646.40 2655.40 2664.40 18.00 F1,F2,F3,H1,H2
L28 2649.60 2658.60 2667.60 18.00 F2,F3,H1,H2,H3
L34 2652.90 2661.90 2670.90 18.00 F3,H1,H2,H3
L39 2656.40 2665.40 2674.40 18.00 F3,H1,H2,H3,G1
L08 2659.40 2668.40 2677.40 18.00 H1,H2,H3,G1
L15 2662.90 2671.90 2680.90 18.00 H1,H2,H3,G1,G2
L22 2666.20 2675.20 2684.20 18.00 H2,H3,G1,G2,G3
L29 2669.40 2678.40 2687.40 18.00 H3,G1,G2,G3
