4. SETUP
4.1. Equipment Needed for Repeater Setup
Parameter Item Quantity Remark
Major Component Smart-Cell Repeater 1 EA Provided by GST
Additional
Components
WALL Mounting Bracket
CD which contains User Manual
V.1.0 and Installation Guide V.1.0
Ethernet Cable 6.6ft (2m)
Ground Cable 6.6ft (2m)
Ground Sems Screw M4 x 8mm
Bracket Sems Screw M6 x 10mm
Lag Screw 12.7mm x 50.8mm
FEU-AMP unit cable
FEU-Wall Bracket cable
1 EA
1 EA
1 EA
1 EA
4 EA
4 EA
4 EA
8 EA
2 EA
Provided by GST
Antenna
Donor ANT
Server ANT
1 EA
1 EA
Not Included
RF Cable Antenna connection Cable TBD Not Included
Testing and
Measuring Equipment
Spectrum Analyzer 1 EA Not Included
4.1.1. Check points before turning on the Repeater
1) System Power Check
① AC electrical power to the repeater should be 110V, input electricity only after
power verification.
2) Input RF Signal Range
① Optimal input RSSI into the repeater is -57dBm ~ -27dBm for
700MHz/850MHz/1900MHz/2100MHz. User should verify input condition of
Donor ANT. If the input RSSI exceeds -27dBm, then external attenuators should
be used.
