User's Manual

Sprint User Manual
3G Indoor Repeater
12
/
23
Waveform Quality Factor > 0.97
Output Power Variation
over Temperature
±2.0dB
3.2 Electrical and Environmental Specifications
ITEM SPECIFICATION REMARK
Power & Consumption 100 ~ 240 VAC,60Hz
Connector Type N-type female
Size 340X300X170
Weight max 40 lbs
Reliability, MTBF 50,000 hours
Enclosure NEMA4
Operating Temperature
-10℃ ~ +50℃
Rel. Humidity 0% ~ 90%
Industry Standards
TIA-97, TIA-98, IS-98D,
IS-2000
Regulatory Approvals FCC, Part24 CDN-IC
Safety Approvals UL1950 or Equiv
3.3 Functions
ITEM FUNCTIONS
Gain Control
• Adjustable DL and UL Gain range 60~80dB
• Display default Gain and current Gain function
AGC
(Auto Gain Control)
• It always operates in Downlink AGC ON status
• To maintain same Downlink output power despite flexible input signal
strength
• To add or subtract Attenuation level referring to AGC Power Limit level.
• Used with the Automatic Setup (Auto Gain Setting)
