User's Manual

Sprint User Manual
3G Indoor Repeater
11
/
23
3. SPECIFICATIONS
3.1 System Specifications(Applicable to both Uplink & Downlink)
ITEM SPECIFICATION REMARK
Transmit Power 23dBm ± 2.0dBm
Downlink 1930MHz ~ 1975MHz
Frequency
Range
Uplink 1850MHz ~ 1895MHz
Gain Range 60dB ~ 80dB DL/UL both
Roll Off ≥ 50dBc @ F(edge)±1MHz
VSWR 1.5 : 1
Delay 8us
In Band
Spurious
Emission
@
Fc±885kHz
≥ 45dBc marker to marker 29dB
@
Fc±885kHz
≥ -45dBc marker to marker 29dB
@
Fc±1.98MHz
≥ -55dBc marker to marker 39dB
Out band
Spurious
Emission
@
Fc±2.25MHz
< -13dBm RBW = 1MHz
Flatness 3.0dB
channel power
measurement
5MHz
5+5MHz or 10MHz
5+5+5MHz or 10+5MHz or 15MHz
Band Select
15+5MHz or 20MHz
Non-contiguous Band
(Maximum 3-band)
Noise Figure
5dB @ Max Gain
12dB @ Min Gain
ALC Range 20dB, 1dB step
Frequency Stability ±0.05ppm
