9.7. HTTP

A HTTP Notification server can listen for notification messages from IP Cameras by triggered events. The HTTP

setting page is shown below. Enter the HTTP details, which include server, user name, and password in the fields.

<Alarm> triggered and <Motion Detection> notifications can be sent to the specified <HTTP> server.

Click “Save” when finished.

Please refer to: 9.8. Application: Send HTTP notification / 9.9. Motion Detection for HTTP Notification settings.

9.8. Application (Alarm Settings)

The IP Camera equips one alarm input and one relay output for cooperating with the alarm system to catch

events’ images. Refer to the alarm pin definition below to connect alarm devices to the IP Camera if needed. The

alarm configuration page is also shown below.

Alarm Pin Definition :

1. Output+

2. Output-

3. Input+

4. Input-
