Installation Instructions

Quick start guide
10
10
8
5
6
14 3
9
2
7
11
12
13
Elements:
1. Power adapter input
2. EC (Temp.) input
3. EC probe input
4. pH probe input
5. Ethernet/LAN input
6. Technician access
7. Reset button
8. Light indicator
9. Add-ons output
10. Screw hangers
11. EC probe
12. pH probe
13. Power adapter
•
•
•
•
•
•
•
Warnings:
Keep out of the reach of children.
Do not unscrew or dismantle the
device under any circumstances.
The device itself is splash-proof
but its connectors are exposed.
Avoid splashing water and keep
the connector inputs dry at all
times.
Keep in a cool and dry place.
Care and maintenance:
Ensure you regularly clean the
sensors and cables once a month
to prevent any build up.
Keep at a normal distance from
your home network router or use
the ethernet connection (5) to
hardwire your device.
Make sure to keep the lids of the
connectors which are not in use
closed at all times.
65 mm
FCC Warning
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
•  Reorient or relocate the receiving antenna.
•  Increase the separation between the equipment and receiver.
•  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•  Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator and your body.
Hydro M ast er
