Replacement Part List

GEAR BOX
BREAK DOWN
1. O.P.S. Output shaft spacer
2. GHU-5 Output shaft
3. RS-125 Output spiral ring
4. NO. 21 1/4 woodruff key
5. G71-3X Bronze gear
6. 08125 Output bearing
7. 08231 Output cup
8. GHU-1 Gear case
Specify machine
9. GHU-4 Engine base
10. 12341 Output seal
11. GHU-2 Output cap
PLEASE SPECIFY IF YOU ORDERING PARTS FOR A ONE-MAN OR A TWO-MAN EARTHDRILL
12. GHU-2GS Output gasket set
13. LM11910 Input cup
14. LM11949 Input bearing
15. I.P.S. Input spacer
16. H1618 Worm gear
17. RS-715 Input spiral ring
18. GHU-6 Input shaft
Specify machine
19. GHU-3GS Input gasket set
20. GHU-3 Input cap
21. 7485 Input seal
22. 3/16 Key Specify square or
Woodruff
GHU 10:1 = Complete C-71-5 & D5 gear box GHU-1M = Complete 1M & 1M5C gear box
1470 S. VICTORIA CT • San Bernardino, CA. 92408 • P.O. BOX 290 •San Bernardino, CA. 92402
Phone [phone] • Toll Free [phone]
Fax [phone] • E-mail: [e-mail]
1 2 3 4 65 7 8 9
10 11 12 7 6
13 14 15 16 18 17
15 14 13 19 21 20
22
