Spec Sheet

Innovative Ductless Mini Split Solution
Submittal Data: UMAT48HP230V1AF
48,000 BTUH Floor/Ceiling Heat Pump System
Job Name Location
Date
Purchaser Engineer
Submitted To For
Unit Designation Schedule No.
GENERAL FEATURES
-Multi-Speed Fan
-4-way Discharge Air
-Swing Louvers
-Wireless Remote Controllers
-Power Failure Recovery
-Wall or Ceiling Mount
-5 yr. Limited Parts & Compressor Warranty (Residential Only)
Cooling
Fan Motor
Output Power 1/3HP
Rated Capacity 48,000 BTU/H FLA 2.1A
Capacity Range 20,400-50,500 BTU/H
Airflow
Power Input (Max) 5,500 W
Cooling Wet (Lo/Hi)
935/1350 CFM
SEER 16.0
Heating Dry (Lo/Hi)
935/1350 CFM
EER 8.7 Sound Level
Heating at 47° F
Cooling (Min/Max)
46/55 dB(A)
Rated Capacity 54,500 BTU/H
Heating (Min/Max)
46/55 dB(A)
Capacity Range 17,500-61,500 BTU/H Dehumidication 1.99 pt/hr
Power Input (Max) 5,400 W
HSPF 9.0
COP 3.5
Normal Operational Voltage
208/230 V, 1 Phase, 60 Hz
Heating at 17° F
Voltage Range
187 - 253 V
Rated Capacity 28,600 BTU/H
MCA
3.0A
MOCP/Breaker Size
15A
Operating Range Communication Wire Size
Cooling (Max)
118°F (48°C)
(Min)
0°F (-18°C) Compressor DC Inverter Driven Rotary
Heating (Max)
75°F (24°C) RLA 35.5 A
(Min)
0°F (-18°C) Refrigerant Type R410A
Refrigerant Piping Data Fan Motor Output Power 2 x 1/6HP
Gas Pipe Size (OD) 5/8-in FLA 2 x 2.0 A
Liquid Pipe Size (OD) 3/8-in Sound Level
Connection Method Flared Cooling/Heating 59/59 dB(A)
Factory Charge 140.8 oz
Additional Charge 0.6 oz/ft
Pre-Charge Length 25-ft
Normal Operational Voltage
208/230 V, 1 Phase, 60 Hz
MAX Refrigerant Pipe Length 230-ft
Voltage Range
187 - 253 V
Main Supply Wire Size
8 AWG
MIN Refrigerant Pipe Length 10-ft
MCA
36.5 A
MAX Refrigerant Pipe Elevation 49-ft
MOCP/Breaker Size
60 A
Power Supply (Dedicated Circuit)
Indoor Unit Data
System Ratings
Outdoor Unit Data
18-2 AWG / 300V THHN
Power Supply (Dedicated Circuit: Size Per Local Code)
Reference Approval
Construction
AHRI Certified Ref No: 7631654
