Spec Sheet

DIMENSIONAL SPECIFICATIONS UMAT48HP230V1AC
INDOOR UNIT DIMENSIONS & WEIGHTS
Units: inch (mm)
A
B C
D F G
in
41.0 31-1/8 33-1/8 35-7/8 11-3/8 (140)
mm (1040) (790) (842) (910) (290) 290
94.6 lbs
110.0 lbs
OUTDOOR UNIT DIMENSIONS & WEIGHTS
Units: inch (mm)
A
B
C 53-1/8 (1350)
D
E
231.0 lbs
253.0 lbs
Notes:
1. Recommended Communication WireType 18-2 AWG Stranded Copper THHN 300V Wire
2. Power wiring size must comply with applicable national and local codes for both ID and OD dedicated circuits.
3. Test conditions are based on AHRI 210/240.
Gas Line Valve
5/8-in OD Flared
Specifications are subject to change without notice. Manufacturer reserves the right to discontinue or modify specifications or designs
without notice or without incurring obligations. All rights reserved.
Gas Line Valve
5/8-in OD Flared
Shipping Weight
37-3/4 (960)
16-1/4 (410)
22-1/2 (570)
14-3/4 (375)
Liquid Line Valve 3/8-in OD Flared
Drain Connector
1-in OD
Liquid Line Valve
Net Weight
Shipping Weight
Net Weight
3/8-in OD Flared
© Gree Corporation 2020 CAT NO: GREE_U-MATCH_SUBMITTAL_CASSETTE_48MBH_021120
