Spec Sheet

Innovative Ductless Mini Split Solution
Submittal Data: UMAT48HP230V1AC
48,000 BTUH Ceiling Cassette Heat Pump System
Job Name Location
Date
Purchaser Engineer
Submitted To For
Unit Designation Schedule No.
GENERAL FEATURES
-Multi-Speed Fan
-4-way Discharge Air
-Internal Condensate Drain Pump
-Wireless Remote Controllers
-Power Failure Recovery
-Sentry Condensate Overflow Protection
-Decorative Grille ( Part# UMAT48GRILLE -Sold Separately)
-5 yr. Limited Parts & Compressor Warranty (Residential Only)
Cooling
Fan Motor
Output Power 1/7HP
Rated Capacity 48,000 BTU/H FLA 1.5 A
Capacity Range 20,400-50,500 BTU/H
Airflow
Power Input (Max) 5,700 W
Cooling Wet (Lo/Hi)
900/1350 CFM
SEER 16.0
Heating Dry (Lo/Hi)
900/1350 CFM
EER 8.7 Air Throw (max) 19.7 ft
Heating at 47° F Sound Level
Rated Capacity 54,500 BTU/H
Cooling (Min/Max)
41/53 dB(A)
Capacity Range 17,500-61,500 BTU/H
Heating (Min/Max)
41/53 dB(A)
Power Input (Max) 5,400 W Dehumidication 2.13 pt/hr
HSPF 9.0 Condensate Drain Lift (Height) 33 in
COP 3.3
Heating at 17° F
Normal Operational Voltage
208/230 V, 1 Phase, 60 Hz
Rated Capacity 27,600 BTU/H
Voltage Range
187 - 253 V
MCA
2.0 A
Operating Range MOCP/Breaker Size
15 A
Cooling (Max)
118°F (48°C)
Communication Wire Size
18-2 AWG / 300V THHN
(Min)
0°F (-18°C)
Heating (Max)
75°F (24°C) Compressor DC Inverter Driven Rotary
(Min)
0°F (-18°C) RLA 35.5 A
Refrigerant Piping Data Refrigerant Type R410A
Gas Pipe Size (OD) 5/8-in Fan Motor Output Power 2 x 1/6HP
Liquid Pipe Size (OD) 3/8-in FLA 2 x 2.0 A
Connection Method Flared Sound Level
Factory Charge 140.8 oz Cooling/Heating 59/59 dB(A)
Additional Charge 0.6 oz/ft
Pre-Charge Length 25-ft
Normal Operational Voltage
208/230 V, 1 Phase, 60 Hz
MAX Refrigerant Pipe Length 230-ft
Voltage Range
187 - 253 V
MIN Refrigerant Pipe Length 10-ft
Main Supply Wire Size
8 AWG
MAX Refrigerant Pipe Elevation 49-ft
MCA
36.5 A
MOCP/Breaker Size
60 A
Indoor Unit Data
System Ratings
Outdoor Unit Data
Power Supply (Dedicated Circuit: Size Per Local Code)
Power Supply (Dedicated Circuit)
Reference Approval
Construction
AHRI Certified Ref No: 7631501
