2545K–AVR–04/07

ATmega48/88/168

Table 12-10. Overriding Signals for Alternate Functions PD7..PD4

Signal

Name

PD7/AIN1

/PCINT23

PD6/AIN0/

OC0A/PCINT22

PD5/T1/OC0B/

PCINT21

PD4/XCK/

T0/PCINT20

PUOE0000

PUO0000

DDOE 0 0 0 0

DDOV 0 0 0 0

PVOE 0 OC0A ENABLE OC0B ENABLE UMSEL

PVOV 0 OC0A OC0B XCK OUTPUT

DIEOE PCINT23 • PCIE2 PCINT22 • PCIE2 PCINT21 • PCIE2 PCINT20 • PCIE2

DIEOV1111

DI PCINT23 INPUT PCINT22 INPUT

PCINT21 INPUT

T1 INPUT

PCINT20 INPUT

XCK INPUT

T0 INPUT

AIO AIN1 INPUT AIN0 INPUT – –

Table 12-11. Overriding Signals for Alternate Functions in PD3..PD0

Signal

Name

PD3/OC2B/INT1/

PCINT19

PD2/INT0/

PCINT18

PD1/TXD/

PCINT17

PD0/RXD/

PCINT16

PUOE 0 0 TXEN RXEN

PUO000PORTD0 • PUD

DDOE 0 0 TXEN RXEN

DDOV 0 0 1 0

PVOE OC2B ENABLE 0 TXEN 0

PVOV OC2B 0 TXD 0

DIEOE

INT1 ENABLE +

PCINT19 • PCIE2

INT0 ENABLE +

PCINT18 • PCIE1

PCINT17 • PCIE2 PCINT16 • PCIE2

DIEOV1111

PCINT19 INPUT

INT1 INPUT

PCINT18 INPUT

INT0 INPUT

PCINT17 INPUT

PCINT16 INPUT

RXD

AIO––––
