(one)) to serve this function. The OC1A pin is also the output pin for the PWM mode timer

function.

PCINT1: Pin Change Interrupt source 1. The PB1 pin can serve as an external interrupt source.

• ICP1/CLKO/PCINT0 – Port B, Bit 0

ICP1, Input Capture Pin: The PB0 pin can act as an Input Capture Pin for Timer/Counter1.

CLKO, Divided System Clock: The divided system clock can be output on the PB0 pin. The

divided system clock will be output if the CKOUT Fuse is programmed, regardless of the

PORTB0 and DDB0 settings. It will also be output during reset.

PCINT0: Pin Change Interrupt source 0. The PB0 pin can serve as an external interrupt source.

Table 12-4 and Table 12-5 relate the alternate functions of Port B to the overriding signals

shown in Figure 12-5 on page 76. SPI MSTR INPUT and SPI SLAVE OUTPUT constitute the

MISO signal, while MOSI is divided into SPI MSTR OUTPUT and SPI SLAVE INPUT.

Table 12-4. Overriding Signals for Alternate Functions in PB7..PB4

Signal

Name

PB7/XTAL2/

TOSC2/PCINT7

(1)

PB6/XTAL1/

TOSC1/PCINT6

(1)

PB5/SCK/

PCINT5

PB4/MISO/

PCINT4

PUOE

INTRC

• EXTCK+

AS2

INTRC

+ AS2 SPE • MSTR SPE • MSTR

PUOV 0 0 PORTB5 • PUD PORTB4 • PUD

DDOE

INTRC

• EXTCK+

AS2

INTRC

+ AS2 SPE • MSTR SPE • MSTR

DDOV0000

PVOE 0 0 SPE • MSTR SPE • MSTR

PVOV 0 0 SCK OUTPUT

SPI SLAVE

OUTPUT

DIEOE

INTRC • EXTCK +

AS2 + PCINT7 •

PCIE0

INTRC

+ AS2 +

PCINT6 • PCIE0

PCINT5 • PCIE0 PCINT4 • PCIE0

DIEOV

(INTRC + EXTCK) •

AS2

INTRC • AS2 11

DI PCINT7 INPUT PCINT6 INPUT

PCINT5 INPUT

SCK INPUT

PCINT4 INPUT

SPI MSTR INPUT

AIO Oscillator Output

Oscillator/Clock

Input

––
