Table of Contents

2545K–AVR–04/07

ATmega48/88/168

0xC1B out SPH,r16 ; Set Stack Pointer to top of RAM

0xC1C ldi r16,low(RAMEND)

0xC1D out SPL,r16

0xC1E sei ; Enable interrupts

0xC1F <instr> xxx

10.4 Interrupt Vectors in ATmega168

Notes: 1. When the BOOTRST Fuse is programmed, the device will jump to the Boot Loader address at

reset, see ”Boot Loader Support – Read-While-Write Self-Programming, ATmega88 and

ATmega168” on page 269.

Table 10-4. Reset and Interrupt Vectors in ATmega168

VectorNo.

Program

Address

(2)

Source Interrupt Definition

1 0x0000

(1)

RESET

External Pin, Power-on Reset, Brown-out Reset and Watchdog System Reset

2 0x0002 INT0 External Interrupt Request 0

3 0x0004 INT1 External Interrupt Request 1

4 0x0006 PCINT0 Pin Change Interrupt Request 0

5 0x0008 PCINT1 Pin Change Interrupt Request 1

6 0x000A PCINT2 Pin Change Interrupt Request 2

7 0x000C WDT Watchdog Time-out Interrupt

8 0x000E TIMER2 COMPA Timer/Counter2 Compare Match A

9 0x0010 TIMER2 COMPB Timer/Counter2 Compare Match B

10 0x0012 TIMER2 OVF Timer/Counter2 Overflow

11 0x0014 TIMER1 CAPT Timer/Counter1 Capture Event

12 0x0016 TIMER1 COMPA Timer/Counter1 Compare Match A

13 0x0018 TIMER1 COMPB Timer/Coutner1 Compare Match B

14 0x001A TIMER1 OVF Timer/Counter1 Overflow

15 0x001C TIMER0 COMPA Timer/Counter0 Compare Match A

16 0x001E TIMER0 COMPB Timer/Counter0 Compare Match B

17 0x0020 TIMER0 OVF Timer/Counter0 Overflow

18 0x0022 SPI, STC SPI Serial Transfer Complete

19 0x0024 USART, RX USART Rx Complete

20 0x0026 USART, UDRE USART, Data Register Empty

21 0x0028 USART, TX USART, Tx Complete

22 0x002A ADC ADC Conversion Complete

23 0x002C EE READY EEPROM Ready

24 0x002E ANALOG COMP Analog Comparator

25 0x0030 TWI 2-wire Serial Interface

26 0x0032 SPM READY Store Program Memory Ready
