Figure 28-45. AREF External Reference Current vs. V
CC
Figure 28-46. Analog Comparator Current vs. V
CC
AREF EXTERNAL REFERENCE CURRENT vs. V
CC
85 ˚C
25 ˚C
-40 ˚C
0
20
40
60
80
100
120
140
160
180
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
ANALOG COMPARATOR CURRENT vs. V
CC
85 ˚C
25 ˚C
-40 ˚C
0
20
40
60
80
100
120
140
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
