334
2545K–AVR–04/07
ATmega48/88/168
Figure 28-35. BOD Thresholds vs. Temperature (BODLEVEL Is 1.8V)
Figure 28-36. Bandgap Voltage vs. V
CC
BOD THRESHOLDS vs. TEMPERATURE
BODLEVEL IS 1.8V
1.76
1.78
1.8
1.82
1.84
1.86
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100
Temperature (C)
Threshold (V)
Rising Vcc
Falling Vcc
BANDGAP VOLTAGE vs. V
CC
-40 C
85 C
1.08
1.085
1.09
1.095
1.1
1.5 2 2.5 3 3.5 4 4.5 5 5.5 6
V
CC
(V)
Bandgap Voltage (V
)
