333
2545K–AVR–04/07
ATmega48/88/168
28.10 BOD Thresholds and Analog Comparator Offset
Figure 28-33. BOD Thresholds vs. Temperature (BODLEVEL is 4.3V)
Figure 28-34. BOD Thresholds vs. Temperature (BODLEVEL is 2.7V)
BOD THRESHOLDS vs. TEMPERATURE
BODLEVEL IS 4.3V
4.2
4.25
4.3
4.35
4.4
4.45
4.5
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100
Temperature (C)
Threshold (V)
Rising Vcc
Falling Vcc
BOD THRESHOLDS vs. TEMPERATURE
BODLEVEL IS 2.7V
2.6
2.65
2.7
2.75
2.8
2.85
2.9
-50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100
Temperature (C)
Threshold (V)
Rising Vcc
Falling Vcc
