ATmega48/88/168
Figure 28-21. Reset Pull-Up Resistor Current vs. Reset Pin Voltage (V
CC
= 2.7V)
28.8 Pin Driver Strength
Figure 28-22. I/O Pin Source Current vs. Output Voltage (V
CC
= 5V)
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
V
CC
= 2.7V
-40 °C
0
10
20
30
40
50
60
70
0 0.5 1 1.5 2 2.5 3
V
RESET
(V)
I
RESET
(uA)
25 °C
85 °C
I/O PIN SOURCE CURRENT vs. OUTPUT VOLTAGE
V
CC
= 5V
85 °C
25 °C
-40 °C
0
10
20
30
40
50
60
70
80
90
0123456
V
OH
(V)
I
OH
(mA)
