Figure 28-17. Standby Supply Current vs. V
CC
(Full Swing Crystal Oscillator)
28.7 Pin Pull-up
Figure 28-18. I/O Pin Pull-Up Resistor Current vs. Input Voltage (V
CC
= 5V)
STANDBY SUPPLY CURRENT vs. V
CC
Full Swing Crystal Oscillator
6 MHz Xtal
(ckopt)
4 MHz Xtal
(ckopt)
2 MHz Xtal
(ckopt)
16 MHz Xtal
12 MHz Xtal
0
50
100
150
200
250
300
350
400
450
500
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
I/O PIN PULL-UP RESISTOR CURRENT vs. INPUT VOLTAGE
V
CC
= 5V
85 °C
25 °C
-40 °C
0
20
40
60
80
100
120
140
160
0123456
V
OP
(V)
I
OP
(uA)
