ATmega48/88/168
28.5 Power-Save Supply Current
Figure 28-15. Power-Save Supply Current vs. V
CC
(Watchdog Timer Disabled)
28.6 Standby Supply Current
Figure 28-16. Standby Supply Current vs. V
CC
(Low Power Crystal Oscillator)
POWER-SAVE SUPPLY CURRENT vs. V
CC
WATCHDOG TIMER DISABLED
25 °C
0
2
4
6
8
10
12
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
STANDBY SUPPLY CURRENT vs. V
CC
Low Power Crystal Oscillator
6 MHz Xtal
6 MHz Res.
4 MHz Xtal
4 MHz Res.
455kHz Res.
32 kHz Xtal
2 MHz Xtal
2 MHz Res.
1 MHz Res.
0
20
40
60
80
100
120
140
160
180
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
