Table of Contents

318

2545K–AVR–04/07

ATmega48/88/168

Figure 28-6. Active Supply Current vs. V

(32 kHz External Oscillator)

28.2 Idle Supply Current

Figure 28-7. Idle Supply Current vs. Frequency (0.1 - 1.0 MHz)

ACTIVE SUPPLY CURRENT vs. V

32 kHz EXTERNAL OSCILLATOR

25 °C

1.5 2 2.5 3 3.5 4 4.5 5 5.5

(V)

(uA)

IDLE SUPPLY CURRENT vs. FREQUENCY

0.1 - 1.0 MHz

5.5 V

5.0 V

4.5 V

4.0 V

3.3 V

2.7 V

1.8 V

0.02

0.04

0.06

0.08

0.1

0.12

0.14

0.16

0.18

0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency (MHz)

(mA)
