316
2545K–AVR–04/07
ATmega48/88/168
Figure 28-2. Active Supply Current vs. Frequency (1 - 24 MHz)
Figure 28-3. Active Supply Current vs. V
CC
(Internal RC Oscillator, 128 kHz)
ACTIVE SUPPLY CURRENT vs. FREQUENCY
1 - 24 MHz
0
2
4
6
8
10
12
14
16
18
04812162024
Frequency (MHz)
I
CC
(mA)
2.7V
1.8V
3.3V
4.0V
4.5V
5.0V
5.5V
ACTIVE SUPPLY CURRENT vs. V
CC
INTERNAL RC OSCILLATOR, 128 KHz
85 °C
25 °C
-40 °C
0
0.02
0.04
0.06
0.08
0.1
0.12
0.14
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
