306
2545K–AVR–04/07
ATmega48/88/168
27.4 Clock Characteristics
27.4.1 Calibrated Internal RC Oscillator Accuracy
Notes: 1. Voltage range for ATmega48V/88V/168V.
2. Voltage range for ATmega48/88/168.
27.4.2 External Clock Drive Waveforms
Figure 27-3. External Clock Drive Waveforms
27.4.3 External Clock Drive
Note: All DC Characteristics contained in this datasheet are based on simulation and characterization of
other AVR microcontrollers manufactured in the same process technology. These values are pre-
liminary values representing design targets, and will be updated after characterization of actual
silicon.
Table 27-1. Calibration Accuracy of Internal RC Oscillator
Frequency V
CC
Temperature Calibration Accuracy
Factory
Calibration
8.0 MHz 3V 25°C±10%
User
Calibration
7.3 - 8.1 MHz
1.8V - 5.5V
(1)
2.7V - 5.5V
(2)
-40°C - 85°C±1%
V
IL1
V
IH1
Table 27-2. External Clock Drive
Symbol Parameter
V
CC
=1.8-5.5V V
CC
=2.7-5.5V V
CC
=4.5-5.5V
UnitsMin. Max. Min. Max. Min. Max.
1/t
CLCL
Oscillator
Frequency
04010020MHz
t
CLCL
Clock Period 250 100 50 ns
t
CHCX
High Time 100 40 20 ns
t
CLCX
Low Time 100 40 20 ns
t
CLCH
Rise Time 2.0 1.6 0.5 μs
t
CHCL
Fall Time 2.0 1.6 0.5 μs
Δt
CLCL
Change in period
from one clock
cycle to the next
22 2%
