302

2545K–AVR–04/07

ATmega48/88/168

26.8.4 SPI Serial Programming Characteristics

Figure 26-9. Serial Programming Waveforms

For characteristics of the SPI module see “SPI Timing Characteristics” on page 309.

MSB

MSB

LSB

LSB

SERIAL CLOCK INPUT

(SCK)

SERIAL DATA INPUT

(MOSI)

(MISO)

SAMPLE

SERIAL DATA OUTPUT
