289
2545K–AVR–04/07
ATmega48/88/168
26.5 Page Size
26.6 Parallel Programming Parameters, Pin Mapping, and Commands
This section describes how to parallel program and verify Flash Program memory, EEPROM
Data memory, Memory Lock bits, and Fuse bits in the ATmega48/88/168. Pulses are assumed
to be at least 250 ns unless otherwise noted.
26.6.1 Signal Names
In this section, some pins of the ATmega48/88/168 are referenced by signal names describing
their functionality during parallel programming, see Figure 26-1 and Table 26-11. Pins not
described in the following table are referenced by pin names.
The XA1/XA0 pins determine the action executed when the XTAL1 pin is given a positive pulse.
The bit coding is shown in Table 26-13.
When pulsing WR
or OE, the command loaded determines the action executed. The different
Commands are shown in Table 26-14.
Table 26-9. No. of Words in a Page and No. of Pages in the Flash
Device Flash Size Page Size PCWORD
No. of
Pages PCPAGE PCMSB
ATmega48
2K words
(4K bytes)
32 words PC[4:0] 64 PC[10:5] 10
ATmega88
4K words
(8K bytes)
32 words PC[4:0] 128 PC[11:5] 11
ATmega168
8K words
(16K bytes)
64 words PC[5:0] 128 PC[12:6] 12
Table 26-10. No. of Words in a Page and No. of Pages in the EEPROM
Device
EEPROM
Size
Page
Size PCWORD
No. of
Pages PCPAGE EEAMSB
ATmega48 256 bytes 4 bytes EEA[1:0] 64 EEA[7:2] 7
ATmega88 512 bytes 4 bytes EEA[1:0] 128 EEA[8:2] 8
ATmega168 512 bytes 4 bytes EEA[1:0] 128 EEA[8:2] 8
