287
2545K–AVR–04/07
ATmega48/88/168
Note: 1. The default value of BOOTSZ1..0 results in maximum Boot Size. See Table 26-11 on page
290 for details.
Notes: 1. See ”Alternate Functions of Port C” on page 81 for description of RSTDISBL Fuse.
2. The SPIEN Fuse is not accessible in serial programming mode.
3. See ”WDTCSR – Watchdog Timer Control Register” on page 53 for details.
4. See Table 27-4 on page 307 for BODLEVEL Fuse decoding.
Table 26-5. Extended Fuse Byte for mega88/168
Extended Fuse Byte Bit No Description Default Value
–7– 1
–6– 1
–5– 1
–4– 1
–3– 1
BOOTSZ1 2
Select Boot Size
(see Table 25-6 on page 281
and Table 25-9 on page 282
for details)
0 (programmed)
(1)
BOOTSZ0 1
Select Boot Size
(see Table 25-6 on page 281
and Table 25-9 on page 282
for details)
0 (programmed)
(1)
BOOTRST 0 Select Reset Vector 1 (unprogrammed)
Table 26-6. Fuse High Byte
High Fuse Byte Bit No Description Default Value
RSTDISBL
(1)
7 External Reset Disable 1 (unprogrammed)
DWEN 6 debugWIRE Enable 1 (unprogrammed)
SPIEN
(2)
5
Enable Serial Program and
Data Downloading
0 (programmed, SPI
programming enabled)
WDTON
(3)
4 Watchdog Timer Always On 1 (unprogrammed)
EESAVE 3
EEPROM memory is
preserved through the Chip
Erase
1 (unprogrammed), EEPROM
not reserved
BODLEVEL2
(4)
2
Brown-out Detector trigger
level
1 (unprogrammed)
BODLEVEL1
(4)
1
Brown-out Detector trigger
level
1 (unprogrammed)
BODLEVEL0
(4)
0
Brown-out Detector trigger
level
1 (unprogrammed)
