2545K–AVR–04/07
ATmega48/88/168
See ”Addressing the Flash During Self-Programming” on page 274 for details about the use of
Z-pointer during Self-Programming.
25.8.14 ATmega168 Boot Loader Parameters
In Table 25-9 through Table 25-11, the parameters used in the description of the self program-
ming are given.
Note: The different BOOTSZ Fuse configurations are shown in Figure 25-2.
For details about these two section, see ”NRWW – No Read-While-Write Section” on page 270
and ”RWW – Read-While-Write Section” on page 270
Table 25-9. Boot Size Configuration, ATmega168
BOOTSZ1 BOOTSZ0
Boot
Size Pages
Application
Flash
Section
Boot
Loader
Flash
Section
End
Application
Section
Boot Reset
Address
(Start Boot
Loader
Section)
11
128
words
2
0x0000 -
0x1F7F
0x1F80 -
0x1FFF
0x1F7F 0x1F80
10
256
words
4
0x0000 -
0x1EFF
0x1F00 -
0x1FFF
0x1EFF 0x1F00
01
512
words
8
0x0000 -
0x1DFF
0x1E00 -
0x1FFF
0x1DFF 0x1E00
00
1024
words
16
0x0000 -
0x1BFF
0x1C00 -
0x1FFF
0x1BFF 0x1C00
Table 25-10. Read-While-Write Limit, ATmega168
Section Pages Address
Read-While-Write section (RWW) 112 0x0000 - 0x1BFF
No Read-While-Write section (NRWW) 16 0x1C00 - 0x1FFF
