User manual

3
NOTICE
SAFETY NOTES
FEATURES
All instructions, warranties and other collateral documents are subject to change at the sole
discretion of Graupner/SJ. For up-to-date product literature, visit
http://www.openhobby.com and click on the support tab for this product.
This is a sophisticated hobby product and NOT a toy. It must be operated with caution
and common sense and requires some basic mechanical ability. Failure to operate this product in
a safe and responsible manner could result in injury or damage to the product or other property. This
product is not intended for use by children without direct adult supervision. Do not attempt disas-
sembly, use with incompatible components or augment product in any way without the approval
of Graupner/SJ. This manual contains instructions for safety, operation and maintenance. It is
essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup
or use, in order to operate correctly and avoid damage or serious injury.
5 channels radio control set with Graupner/SJ HoTT 2.4 GHz technology(Hopping Intellective Telemetry)
The use of up to 75 channels ensures extreme operating reliability and immunity to external
interference.
Real-Time Telemetry analysis.
Displaying Telemetry data and programming receiver outputs with the optional Graupner/SJ
Smart-Box and the optional sensors.
Future-proof update capability using data interface.
Advanced HoTT wireless trainer system makes Teacher and Pupil system more enjoyable and gives
user convenience for the teaching/learning.
Simple, ultra-fast binding of transmitter and receiver.
Extremely fast re-binding, even at maximum range.
Do not fly your model near spectators, parking areas or any other area that could result in injury
to people or damage of property.
Ensure that all channels are working in the proper manner.
Perform a ground range check prior to the initial ight of the day.
The transmitter shouldn’t be switched off at any time during ight.
Don’t move or touch the transmitter antenna during ight.
Do not y during adverse weather conditions. Poor visibility can cause disorientation and loss of
control of your aircraft. Strong winds can cause similar problems.
We strongly recommend to set the Failsafe function and also recommend that the preset Failsafe
would be idle position.
You need to set the function of the transmitter after removing a power battery from a model or
stopping a engine of a model.
Ensure that all your batteries have been properly charged prior to ight.
We recommend to only to use adapter when you charge the battery of the transmitter and receiver.
WARNING
Read the ENTIRE instruction manual to become familiar with the features of the
product before operating. Failure to operate the product correctly can result in dam-
age to the product, personal property and cause serious injury.
SPECIFICATION
◎
◎
◎
Frequency band
Modulation
Output power
Current drain
Operating voltage
2.4~2.4835GHz
FHSS
100mW
Approx 125mA
3.4V~6V
2.4~2.4835GHz
FHSS
Approx 70mA
3.6V~8.4V
Transmitter T5/mz-10
Receiver GR-12
