Items
Video Monitor - The section displays live video streams from the selected devices.
Device Operation
Connect All – Click this button to connect to all devices that are configured in NVR, except
those which are set to record using a schedule.
Disconnect All – Click this button to disconnect all devices that are configured in NVR, except
those which are set to record using a schedule.
Record All – Click this button to record video streams from all configured devices, except those
which are set to record using a schedule. The recorded file will be saved in
C:\GS_Record.
Stop All – Click this button to stop recording video streams from all configured devices, except
those which are set to record using a schedule.
Device Configuration
Search – Click to search other Grandstream DVS or IP Cameras on the LAN.
Add a Device – Click to add a device to NVR.
Delete Device – Click to delete the selected device from NVR.
Delete All – Click to delete all devices from NVR.
GS_NVR Configuration
Schedule – The tool is used to configure an auto recording schedule. You can add, modify
and delete time schedules here.
Replay – This tool provides the ability to replay recorded videos. It also provides a search
function which allows you do a search based on the start time, end time, IP address, and
channel.
System – This is where you select the recording drives, recording settings and other general
settings.
Lock GS_NVR – Click to lock GS_NVR. Once GS_NVR is locked, the settings of Device
Operation, Device, and System Configuration sessions, except Relay, can’t be
changed.
Device List – This section lists all the devices added to the NVR. The device status and Recording
status will also be shown in this section.
GS_NV
R
–
Main Windo
w
