HT801 Administration Guide
Disable DTMF
Negotiation
Uses above DTMF order without negotiation. Default is No.
Generate
Continuous
RFC2833 Events
When enabled the RFC2833 events are generated until key is released. Default is No.
Send Hook Flash
Event
Default is No. If set to yes, flash will be sent as DTMF event.
Flash Digit Control
Overrides the default settings for call control when both channels are in use
Enable Call
Features
Enables do not disturb, call forward and other call features via the local feature codes
on the base. Otherwise, ITSP feature codes can be used. Default is Yes.
Off Hook Auto Dial
Configures a user ID or extension number that is automatically dialed when off-hook.
Only the user part of a SIP address needs to be entered. The HT801 will automatically
append the “@” and the host portion of the corresponding SIP address.
Off Hook Auto Dial
Delay
Specifies the auto-dial delay after off hook.
Proxy-Require
Determines a SIP Extension to notify the SIP server that the HT801 is behind a
NAT/Firewall.
Use NAT IP
Defines NAT IP address used in SIP/SDP messages. It should only be used if required
by ITSP.
Use SIP User Agent
Header
Configures the SIP User-Agent Header.
Distinctive Ring
Tone
Customizes the Ring Tone 1 to 3 with associate caller ID: when selected, if caller ID is
configured, then the device will ONLY use this ring tone when the incoming call is from
the Caller ID. System Ring Tone is used for all other calls. When selected but no Caller
ID is configured, the selected ring tone will be used for all incoming calls using the FXS
port. Distinctive ring tones can be configured not only for matching a whole number, but
also for matching prefixes. In this case symbol * (star) will be used.
For example: If configured as *617, Ring Tone 1 will be used in case of call arrived
from the area code 617. Any other incoming call will ring using cadence defined in
parameter System Ring Cadence located under Advanced Settings Configuration page.
Note: If server supports Alert-Info header and standard ring tone set (Bellcore) or
distinctive ring tone 1-10 is specified, then the ring tone in the Alert-Info header from
