P a g e | 30
HT801 Administration Guide
Authenticate
server certificate
domain
Configures whether to validate the domain certificate when download the
firmware/config file. If it is set to "Yes", the phone will download the firmware/config file
only from the legitimate server. The default setting is "No".
Authenticate
server certificate
chain
Configures whether to validate the server certificate when download the firmware/config
file. If it is set to "Yes", the phone will download the firmware/config file only from the
legitimate server. The default setting is "No".
Trusted CA
Certificates
Uses the certificate for Authentication if “Check Domain Certificates” is set to “Yes”
under “Account” -> “SIP Settings”.
Allow Incoming SIP
Messages from SIP
Proxy Only
Checks SIP address of the Request URI in the incoming SIP message; if it doesn't
match the SIP server address of the account, the call will be rejected. Default is No.
Use Privacy
Header
Adds “Privacy” header if special feature is set to “Default”, and not “CBCOM”.
Use P-Preferred-
Identity Header
Adds “PPI” header if special feature is set to “Default”, and not “CBCOM”.
SIP REGISTER
Contact Header
Uses
Specify which address (LAN or WAN address) the device will detect to use it in SIP
Register Contact Header. Default is LAN Address.
SIP T1 Timeout
Defines T1 timeout value.
It is an estimate of the round-trip time between the client and server transactions.
For example, the HT801 will attempt to send a request to a SIP server. The time it takes
between sending out the request to the point of getting a response is the SIP T1 timer.
If no response is received the timeout is increased to (2*T1) and then (4*T1). Request
re-transmit retries would continue until a maximum amount of time defined by T2.
Default is 0.5 seconds.
SIP T2 Interval
Identifies maximum retransmission interval for non-INVITE requests and INVITE
responses. Retransmitting and doubling of T1 continues until it reaches T2 value.
Default is 4 seconds.
SIP Timer D
Configure the SIP Timer D defined in RFC3261. 0 - 64 seconds. Default 0
DTMF Payload
Type
Defines payload type for DTMF using RFC2833.
Preferred DTMF
method (in order)
Sorts DTMF methods (in-audio, via RTP (RFC2833) or via SIP INFO) by priority.
