HT801 Administration Guide
3. sent or received SIP message (DEBUG level)
4. SIP message summary (INFO level)
5. inbound and outbound calls (INFO level)
6. registration status change (INFO level)
7. negotiated codec (INFO level)
8. Ethernet link up (INFO level)
9. SLIC chip exception (WARNING and ERROR levels)
10. memory exception (ERROR level)
The Syslog uses USER facility. In addition to standard Syslog payload, it contains the
following components: GS_LOG: [device MAC address] [error code] error message.
Example: May 19 02:40:38 192.168.1.14 GS_LOG: [00:0b:82:00:a1:be][000]
Ethernet link is up
Send SIP Log
Configures the HT801 to send a replicate of the SIP packets on the syslog. Default is
No
Download Device
Configuration
Downloads actual device configuration file in .xml format.
Download Device
XML Configuration
Downloads actual device configuration file in .xml format.
Upload Firmware
Allows the user to upgrade the firmware with a single firmware file by browsing and
loading the file from your computer (local directory).
Upload
Configuration
Allows users to upload the configuration file by browsing and loading it from computer
(local directory).
FXS Port Page Definitions
Table 9: FXS Port
FXS Port
Accounts Active
Activates / Deactivates the accounts.
Primary SIP Server
Configures SIP server IP address or domain name provided by VoIP service provider.
This is the primary SIP server used to send/receive SIP messages from/to HT801.
Failover SIP Server
Specifies failover SIP server IP address or domain name provided by VoIP service
provider. This server will be used if the primary SIP server becomes unavailable.
Prefer Primary SIP
Server
Selects to prefer primary SIP server. The account will register to primary Server if
registration with Failover server expires. Default is No.
