HT801 Administration Guide
address. For IP address, add 0 before the digits if the digits are less than 3 (i.e. - 192.168.0.26
should be key in like 192168000026. No decimal is needed).
 Key entry cannot be deleted but the phone may prompt error once it is detected.
Configuration via Web Browser
The HT801 embedded Web server responds to HTTP GET/POST requests. Embedded HTML pages allow
a user to configure the HT801 through a web browser such as Google Chrome, Mozilla Firefox and
Microsoft’s IE.
Accessing the Web UI
1. Connect the computer to the same network as your HT801.
2. Make sure the HT801 is booted up.
3. You may check your HT801 IP address using the IVR on the connected phone.
Please see Obtain HT801 IP Address via Connected Analogue Phone
4. Open Web browser on your computer.
5. Enter the HT801’s IP address in the address bar of the browser.
6. Enter the administrator’s password to access the Web Configuration Menu (default password is:
admin).
Note: The computer must be connected to the same sub-network as the HT801. This can be easily done
by connecting the computer to the same hub or switch as the HT801.
Web UI Access Level Management
There are two default passwords for the login page:
User Level
Password
Web Pages Allowed
End User Level
123
Only Status and Basic Settings
Administrator Level
admin
All pages
The password is case sensitive with maximum length of 25 characters.
When changing any settings, always submit them by pressing Update or Apply button on the bottom of
the page. After submitting the changes in all the Web GUI pages, reboot HT801 to have the changes take
effect if necessary; most of the options under the Advanced Settings and FXS Port page require reboot.
Saving the Configuration Changes
After users makes changes to the configuration, pressing Update button will save but not apply the changes
until Apply button is clicked. Users can instead directly press Apply button. We recommend rebooting or
powering cycle the phone after applying all the changes.
